2000rpm 24VDC Speed Gate Servo Motor 100W With Gearbox

  • 1
  • 2
  • 3

Place of Origin : China

Brand Name : JIAYU

Model Number : EBS59R-100A-20XP4E-B6EL-S1-00

Certification : CE

Packaging Details : pakeage

MOQ : 2pcs

Price : Negotiable

Delivery Time : 10-15days after payment

Payment Terms : TT

Supply Ability : 500pcs per month

Usage : swing barrier gate

Type : SERVO MOTOR

Torque : 9.4N.m

Speed(RPM) : 2000rpm

Continuous Current(A) : 6A

Rated voltage : 24VDC

Rated power : 100Watt

Continuous rated torque : 0.5N.m

Peak current : 12A

Encoder resolution : 9600ppr

Contact Now

Speed Gate Motors 2000rpm 24VDC 100 Watt with gearbox for servo motor

Product description of Speed Gate Motors

turnstile servo motor series are designed to working with swing barrier gate, speed gate and tripod turnstile control pedestrian entering and exiting, adopts 2400 lines encoder, suitable for indoor and outdoor situation, easy to install, and the dc servo motor widely use for applications like stadium, apartment, gym, museum, station, library and factory etc.

Why choose us

1. Our price is reasonable;

2. We can accept small orders;

3. Sample order delivery time is in 5 days, mass quantity order lead time is 7-10 days;

4. We can accept payment via paypal, T/T and L/C;

5. Our products quality assurance is 1 year, and we can provide you professional technical support;

6. We accept products customize.

Advantages of Speed Gate Motors

  • High-resolution position feedback with 2400 lines can realize accurate positioning Service life is not less than
  • 6 million times. Authoritative appraisal by third party testing institution.
  • 300mm acrylic door panel, opening time up to 0.3 seconds.
  • Cooperate with the servo vector algorithm, can achieve sensitive anti-pinch protection.

2000rpm 24VDC Speed Gate Servo Motor 100W With Gearbox
2000rpm 24VDC Speed Gate Servo Motor 100W With Gearbox



2000rpm 24VDC Speed Gate Servo Motor 100W With Gearbox



Dimension of Speed Gate Motors

Type
SERVO MOTOR
Torque
9.4N.m
Speed(RPM)
2000rpm
Continuous Current(A)
6A
Efficiency
IE 4
Rated voltage
24VDC
Rated power
100Watt
Continuous rated speed
2000rpm
Continuous rated torque
0.5N.m
Continuous rated current
6A
Peak current
12A
Output speed
100rpm
Output torque
9.4N.m
Encoder resolution
9600ppr
Weight of motor
1.3kg
2000rpm 24VDC Speed Gate Servo Motor 100W With Gearbox
2000rpm 24VDC Speed Gate Servo Motor 100W With Gearbox

Company profile

Shenzhen Jiayu Mechatronic CO., Ltd, is a high-tech enterprise with multiple invention patents and software copyrights such as servo drive and channel gate control technology. Jiayu is committed to the R&D, production, sales and pre-sales and after-sales service of the core module of the automatic gate control movement. It is a main module supplier in the domestic gate control industry and provides professional product solutions for customers.
The company's technology stems from mature domestic and foreign technology transfer and independent research and development. The products are localized and the core technology is independently controllable. The company introduced advanced control technology and manufacturing technology from Germany and Switzerland, and has an experienced R&D and manufacturing team. In the application field of security gate control gate equipment, it has realized infrared and light curtains.
In the future, the company will focus more on the improvement of product performance and quality, and continue to build the top brand of electronic control of channel gates.
2000rpm 24VDC Speed Gate Servo Motor 100W With Gearbox

FAQ

Q1: Can I install it myself?
A: Yes, it will be easy to install. We will have installation instructions and videos.
Q2: Is the product waterproof?
A: Yes, our products are waterproof and can be used outdoors.
Q3: Are you a distributor or a manufacturer?
A: Hello,we are A manufacturer, the factory sells directly, the price and service have advantages.

Q4: How is the freight calculated?
A: It varies according to the delivery address. For details,you can consult the online
customer service staff.
Q5: How long is the production cycle?
A: Conventional products are basically available in stock, and the production cycle of customized products is about one week.
